BHC - 9 "500 HORSEPOWER" CHOPPER ! ! !

THAT'S ONE BIG ASS BIKE !



BHC-9 502
Specs | Features

Engine
Type
Liquid Cooled V-8

Horsepower
502 @ 5200 rpm

Torque
567 Ft.Lbs. @ 4200 rpm

Block
Cast Iron - 4 bolt main

Cylinders
Aluminum (110cc)

Valvetrain
2.25"Int. / 1.88"Exh

Size
502 c.i. (8200cc)

Compression
9.6:1

Carburetor
Holley 850 cfm

Exhaust
2.5" with dual mufflers

Transmission
3-speed automatic w/rev.

Final Drive
Shaft, narrowed Ford 7.5" (open)


Dimensions
Overall Length
("32) 117" / (`57) 131" / (Truck) 138"

Wheel Base
83.5"

Seat Height
29.0"

Rake
35.0 degrees

Grd. Dlearance
6.5"

Frame Width
60.0"

GVWR
2293 lbs.

Dry Weight
1700 lbs.


Tires/Wheels
Front
130/90-16, 3.50"x16.0"

Rear
275/60R-15, 10.0"x15.0"


Suspension (Adj. Preload)
Front
63mm inverted forks, 3.5" travel

Rear
Dual 17" coilover shocks, single 17.5" rebound damper


Brakes
Front
Dual four-piston calipers, 12.6" floating disc

Rear
9.0" drum brakes


Fuel
Tank
8.5 gal.

Reserve
3.5 gal.

High/Low MPG
18/13
